Targeting host-microbial interactions to develop otitis media therapies

Globally, there are ~709 million cases of acute otitis media (OM), ~31 million cases of chronic OM and 21 000 deaths from OM complications each year¹. In Australia, almost every child will experience an episode of OM by their second birthday. One quarter of Australian children will suffer from recurrent or persistent OM and hearing loss, for which grommet surgery is recommended to improve hearing and reduce the risk of infection. Approximately 35 000 surgeries for OM are conducted each year in Australia².

Acute OM (AOM) involves inflammation of the eardrum, which is often painful and associated with fever. Children that suffer from recurrent AOM (three episodes in 6 months or ≥4 in 12 months) are usually referred for grommet surgery (Figure 1a). In some children bacteria are never fully cleared and mucous (generated by the child’s immune response to presence of bacteria) persists behind the eardrum; this is known as OM with effusion (OME) or ‘glue ear’. Figure 1b (and Video S1, available as Supplementary material to this paper) shows aspiration of the sticky glue from the middle ear by an ENT surgeon. OME can occur without a preceding AOM episode. Persistent ‘glue’ in a child’s ear results in conductive hearing loss and if left untreated can have a devastating impact on a child’s learning, and social and emotional well-being^2,3. This complication disproportionately affects Aboriginal and Torres Strait Islander children, who suffer the highest reported rates of OM and associated hearing loss in the world – more than double the incidence in non-Aboriginal Australian children².

Figure 1.  Grommet insertion and removal of effusion from the middle ear. (a) Otoscopy image of a grommet (small plastic tube) surgically inserted into the tympanic membrane for treatment of acute otitis media or otitis media with effusion (OME) (image courtesy of Clinical A/Professor Jafri Kuthubutheen). (b) Aspiration of middle ear fluid ‘glue’ from a child with OME, via an incision in the tympanic membrane and prior to grommet insertion (image courtesy of Professor Harvey Coates AO).

Potential OM pathogens (otopathogens) reside in the nasopharynx and adenoids, usually as asymptomatic colonisers. Transition from colonisation of the upper respiratory tract to middle ear infection often involves a preceding respiratory virus infection, which aids otopathogen ascension to the middle ear through promotion of bacterial proliferation and increased mucous production⁴. Nontypeable Haemophilus influenzae (NTHi), Streptococcus pneumoniae and Moraxella catarrhalis are the leading otopathogens⁵. We have shown that these otopathogens survive in the ‘glue’ (biofilm) in the middle ear^6,7 (also shown in Figure 2), where they are up to 1000 times more resistant to antimicrobials and can evade host immune defences⁸. Recently, we have demonstrated that children with bacterial otopathogens detected in their middle ear at the time of grommet surgery are three times more likely to require repeat OM surgery⁹. Thus, ensuring that otopathogens are cleared from the middle ear at the time of first grommet surgery could be a strategy for preventing disease recurrence. Preventing the first episode of OM would be even better.

Figure 2.  Maximum projection Confocal Laser Scanning microscopy images demonstrating presence of biofilm in middle ear effusion from a child undergoing grommet surgery for recurrent acute otitis media. (a) Live/dead staining of middle ear effusion demonstrating presence of live bacteria (green) surrounded by extracellular host DNA (red) within mature bacterial biofilms. (b) Fluorescence in situ hybridisation on the same middle ear effusion demonstrating multi-species bacterial biofilms using the following 16s rRNA probes: universal bacterial probe (red), S. pneumoniae (green), and H. influenzae (grey) plus Hoechst 33342 staining for all DNA (blue). S. pneumoniae and other unidentified bacteria were observed within biofilms throughout the host DNA in the middle ear fluid. Scale bar = 37.5 µm.

Cochrane reviews of randomised clinical trials (RCTs) have indicated that treating AOM and OME with antimicrobials only has a modest benefit on the symptoms of OM¹⁰. Long-term low-dose antibiotic treatment has been shown to prevent occurrence of AOM in high-risk children¹¹, but this must be balanced against the risk of adverse effects such as diarrhoea. Antibiotic use, particularly prolonged low-dose use, can also contribute to the growing threat of antimicrobial resistance.

Evidence on the effectiveness of OM surgery for OM is poor; a Cochrane review of five RCTs revealed only low-quality evidence for the benefits of grommet surgery¹². While grommets do improve hearing in the short-term, they can also block with pus or lead to persistent otorrhoea (runny ears)¹³. Furthermore, disease often recurs in children, with >30% of patients returning for repeat grommets¹³. While private surgery waitlists for grommet surgery are only 4 to 6 weeks, the current wait time for grommet surgery at public Australian hospitals is unacceptably long at two years. This is an exceptionally long time for a child to suffer from reduced hearing, which can have major impacts on speech development, education outcomes and social and emotional wellbeing^2,3.

Vaccination remains the gold standard for preventing infections. However, because NTHi has high strain diversity and no polysaccharide capsule, and S. pneumoniae has high serotype diversity, it is challenging to develop effective OM vaccines. Currently no OM-targeted vaccines are licensed¹⁴.

Both orally and nasally delivered Lactobacillus and α-Streptococci species can have a moderate untargeted impact on recurrent OM¹⁵. However, there is no evidence that probiotics protect against initial episodes of OM (Cochrane review of 16 RCTs)¹⁵.

Hydrogels that are liquid at room temperature and gel-like at 37°C can be used for controlled delivery of OM therapies. Otiprio^® is a new licenced therapy that delivers the antibiotic ciprofloxacin over 10–14 days in a thermoresponsive gel¹⁶. This gel can be applied into the middle ear at the time of grommet surgery, removing the need for parental application of antibiotic drops and thereby enhancing compliance. However, antibiotics, even when delivered in a slow-release gel, will have limited effect on established biofilms.

Since the discovery of biofilm in the middle ear of OM patients¹⁷, it is now widely accepted that persistence of infection and recalcitrance to treatment is predominantly driven by biofilm. Biofilms in the ears of children with OM are composed of a combination of host and microbial factors that protect the otopathogens⁶. Researchers are targeting biofilms to enhance treatment for recurrent AOM and chronic OME.

1. Therapeutic anti-biofilm vaccine: antibodies to NTHi proteins (PilA and OmpP5) have been shown to disrupt established NTHi biofilms in the chinchilla model of OM¹⁸. The biofilm destabilisation is antibody mediated and occurs by targeting the type IV pilus (PilA) responsible for twitching motility, and also the tightly co-regulated quorum signalling molecule (LuxS), both of which are essential for biofilm formation and dispersal¹⁸. Otopathogens released from the destabilised biofilm are highly susceptible to antibiotics¹⁹. The PilA protein is included in a tri-valent sub-unit NTHi vaccine that was tested in clinical trials in adults with chronic lung disease²⁰. While PilA vaccination was safe and induced high antibody titres in the trial, the ability of these antibodies to destabilise OM biofilms in humans has not been assessed. Future trials with antibiofilm therapeutic vaccines in children with chronic NTHi OME are warranted.

2. Antibody therapy: Bacterial extracellular DNA (eDNA) is abundant within bacterial biofilms. This eDNA is arranged in lattices and the critical protein that maintains the biofilm structure is integration host factor (IHF). IgG or Fab-fragments targeting protective epitopes within the DNA-binding tip domains of IHF have been shown to disrupt established biofilms in vitro and to mediate resolution of disease in the chinchilla OM NTHi biofilm model²¹.

3. Anti-neutrophil extracellular trap (NET) therapy: Dornase alfa (Pulmozyme^®) is a DNAse-based therapy routinely used to breakdown biofilm in the lungs of cystic fibrosis (CF) patients. We have shown that Pulmozyme^® breaks down NET-derived DNA in middle ear biofilms from OM patients to allow antibiotics to effectively kill the remaining otopathogens in vitro⁶. Our Phase I trial (CTN#2011/0635) in 60 children demonstrated that Pulmozyme^® application into the middle ear at time of grommet surgery was safe, with no adverse events (manuscript in preparation). Our current Phase II randomised control trial is assessing safety and effectiveness of five daily applications of Pulmozyme^® post-surgery (ACTRN12619001306101). Study end-points include safety and tolerability of an extended dosing regimen, recurrence of OM, and need for repeat surgery within 2 years of treatment.

Progress on vaccine development for OM prevention was reviewed following the 2019 international OM meeting¹⁴. In brief, multi-species vaccines are required to prevent OM but their development is challenging. However, vaccines against NTHi and M. catarrhalis, and pneumococcal vaccines with broader serotype coverage, are all in current clinical trials. Vaccines against respiratory viruses are also useful in preventing OM, as demonstrated for influenza¹⁴, and must be tested for new vaccines where possible, i.e. respiratory syncytial virus vaccines. Development of anti-biofilm prophylactic vaccines hold great promise with pre-clinical models demonstrating protection from biofilm formation in the middle ear²².

The human respiratory microbiome has been described as ‘the gatekeeper to respiratory health’²³ and a potential source of novel therapies. The use of respiratory commensal bacteria as probiotics, rather than gut commensals, for OM prevention is under investigation, with evidence of effectiveness in some but not all studies²⁴. We demonstrated that the human respiratory commensal Haemophilus haemolyticus can be used to inhibit NTHi colonisation and infection of human respiratory epithelium in vitro²⁵. In addition, intranasal administration of a closely related murine commensal, Muribacter muris, prevented NTHi colonisation and development of NTHi OM in mice²⁶. Inflammatory responses to NTHi were curbed in mice receiving M. muris²⁶, which is important given that inflammation plays a major role in OM pathogenesis including neutrophil recruitment and NET formation. We are now undertaking a first-in-human study on the safety and tolerability of intranasally delivered H. haemolyticus to healthy adults prior to clinical trials in children to assess impact on OM prevention.

Fundamental research into human-microbial interactions involved in OM has led to significant advances in developing novel approaches to treat and prevent OM. Engaging stakeholder recognition in the value of OM prevention is essential to ensure further investment in development of these new OM therapies. Better treatment and prevention of OM will improve antimicrobial stewardship and conserve healthcare resources, and more importantly help bring equity to hearing health and educational outcomes: when kids can hear, they can learn.
